nodeMINI | IIoT Gateway

Starting from USD195

Regular price $245.00

Quantity

(See Full Product Details )

This webstore is for test samples.
Contact us directly for volume enquiries.

Ex-warehouse stock typical lead time: 2 weeks worldwide

Processing Core, RAM & Storage	NXP i.MX9352, dual core ARM Cortex-A55, 1.7GHz 2GB RAM 32GB eMMC flash storage
Supported Industrial Protocols	Modbus TCP/RTU CAN Bus J1939/OBD2/FD Serial RS485
Cloud Clients	AWS IoT Core Azure IoT Hub Ubidots Google Cloud Platform Integrated MQTT client with TLS security
Networking options	LAN with Ethernet 4G/LTE CAT-4 Cellular module Telit LE910 Optional WiFi & Bluetooth
I/O & Ports	1 x Gbit Ethernet, RJ45 connector 1 x USB2.0 host port (type C connector) 1 x CAN FD port 1 x Serial RS485 port Optional 3 x Digital I/Os
Physical	83mm x 55mm x 28mm Rugged Aluminium Enclosure Screwed mounting plate or DIN rail clip (added on accessories)
Asset Tracking	GPS (mutually exclusive with WiFi module)
Power Supply	12~24 VDC (-20%/+20%)
Operating Temperature	0C~60C Operating Temperatures
Certifications	CE IMDA
Product Warranty	5 Year Manufacturer Warranty

BOX INCLUDES

1 x nodeMINI edge IIoT gateway
1 x LTE/4G cellular Antenna
